16G FC SFP+_Shenzhen Pacific Technology Co.,Ltd

16G FC SFP+

Our 16G SFP Module, 16G Transceiver and 16G Fiber Channel SFP Module are high-speed optical transceiver modules designed for 16G Fibre Channel (16G FC) storage area networks (SAN) and data centers. Supporting up to 14.025Gbps data rate, hot-pluggable, compliant with SFP MSA & SFF-8472, with DDM/DOM function. Available in 850nm MMF (100m/300m) and 1310nm SMF (10km/20km) options. Wide compatible with mainstream switches, stable transmission, low power consumption, ideal for enterprise-level storage interconnection and high-speed fiber communication.

Model:

16G Fiber Channel SFP Module

Inquiry

Optical Transceivers

10G Transceiver

SFP Transceiver

40G QSFP+

100G QSFP28 Transceiver

16/25/32G Transceiver

200/400/800G Transceiver

PON SFP

1*9 Transceiver

DAC/AOC Cable

Fiber to Ethernet Converter

OLT

ONU/ONT

1.25G/2.5G XPON STICK

Accessory

SFP Programmer

16G Fiber Channel SFP

Features

Hot pluggable SFP+ MSA form package, SFP+ MSA compliant
+3.3V power supply
Supports 14.025Gb/s data rate
Optional fiber channel rate 4.25/8.5/14.025Gb/s
I2C management interface
RoHS compliance
Operating temperature range: 0~70°C(Commercial) / -40~85℃(industrial)
Duplex LC Connector

Standard Part

P/N	Data Rate	Reach	Wavelength	Rx	Output Power	Sensitivity
PAC-16G-SR	16Gbps	100M	850nm VCSEL	PIN	-7.8~1dBm	≤-12dBm
PAC-16G-LR	16Gbps	10KM	1310nm DFB	PIN	-4~2dBm	≤-12dBm
PAC-16G-ER	16Gbps	40KM	1550nm DFB	PIN	-1~3dBm	≤-14dBm
