Supports 100Base-FX standard;
Supports auto MDI-MDIX function;
LED display for link/activity, full/half duplex, 10/100M
Supports modified cut-through frame forwarding for low latency;
Supports pure converter mode data forwarding for extreme low latency;
Supports flow control for full and half duplex operation;
Bandwidth control;
Forward 1600 bytes packet for management;
Max. transmission distance can be 120km;
SC(default)/FC/ST supported.
| Part Number | Data Rate | Wavelength | Reach | Connector | Source | Tx Power | Rx Sensitivity |
|---|---|---|---|---|---|---|---|
| PAC-FEMC-2A/B | 10/100Mbps | 1310/1550nm | 2km | SC | FP | -15~-3db | ≤-28db |
| PAC-FEMC-25A/B | 10/100Mbps | 1310/1550nm | 25km | SC | FP | -15~-3db | ≤-34db |
| PAC-FEMC-40A/B | 10/100Mbps | 1310/1550nm | 40km | SC | FP/DFB | -5~0db | ≤-34db |
| PAC-FEMC-80A/B | 10/100Mbps | 1490/1550nm | 80km | SC | DFB | -5~0db | ≤-34db |
| PAC-FEMC-100A/B | 10/100Mbps | 1490/1550nm | 100km | SC | DFB | 0~5db | ≤-34db |
| PAC-FEMC-120A/B | 10/100Mbps | 1490/1550nm | 120km | SC | DFB | 0~5db | ≤-34db |
